Tutorial 1 Part 1

Available in: FREE, Plus, PRO & Architectural

First click on the Page button .

We require an 'A4', 'Landscape' sheet with a scale of '1:1'. Match the settings to the left and click 'OK' to confirm and exit the dialog box.

Now make sure that the grid is switched OFF, use the grid button Grid toggle button if required.

Now click on the units button Units command and click 'OK' when the settings match those to the left, ensuring the 'Linear' 'Cursor Increment' is set to '5.00'.

Switch on the 'Sheet Border' by selecting the display button Display option. In the dialog make sure that 'Sheet Border' is switched ON below.
